Egg Tray Production Line
- By Little Dianne
- •
- 04 Apr, 2018
- •
The egg tray production line is basically consisting of three systems
Pulping system
Molding system
Drying system
Assistant equipment such as burners, air compressors and hot presser machines will probably be required. We're going to have a look at each process in more detail in order to know how the fabrication egg tray production line for sale works.
Pulping system
This is the simple paper mill. It basically contains waste paper being fed into hydra pupler. Waste papers can include all type of papers whether it's office papers, waste cartons or magazines. The hydra pulper either can be placed above or underground. After placing the waster papers in to the pulper, crushing and shredding process kicks off inside water-filled drum. This really is to maintain the pulp consistency at about 4% to fivePer cent. The next phase that'll be done is adding dyes and water-proof chemicals. The mixture will remain at the pulper for approximately 40 minutes then moved to the vibrating screen to filter any impurities. This is achieved through vibration and water flow. Pulping system basically consists of 3 pulp pools, 2 are widely-used from the production process while 1 for standby. Pulp experiences the 1st pool. That's where grinding takes place. It's then utilized in the 2nd pool where water is added to dilute the pulp prior to being used in the molding system.
Molding system
This is actually the main part of the egg production line. It includes the next equipment
Egg box mold
Drying tunnel
Transfer arm
Vacuum pump
Molding drum
Control cabinet
It consists of a rotating drum on which multiple forming mold are fixed. The drum rotates at an even speed with one area of the mold inserted inside the tank. Vacuum pump will be turned on to suck the pulp to remove extra water and which makes it mold as well. The drum is constantly rotate until the mold has exposure to transfer snatcher. As suggested by its name, the transfer snatcher will suck the fibre out of your mold. This is achieved with the aid of air pressure which pushes the fibre outwards. The pulp fibre will then be utilized in the drying tunnel through a conveying tunnel. Click here to know more: http://eggtraymachines.net/pulp-molding-machine/.
Drying system
This is actually the last means of the egg tray production line. It contains the subsequent equipment
Drying oven
Egg box mold
Trays
After being mold into the required shapes, the sub-finished pulps are fetched with the transfer arm and then on placed on metallic tray. The conveyor might carry the metal tray in a drying oven. This can be to evaporate the moisture leaving it approximately 5-8% wet. One can possibly decide on either single layer or multi-layer drying tunnel. Taking a single layer will set you back less community . consumes a lot of space and. A counter is employed to count finished pulp products that come out. The oven may use different fuels including biogas, natural gas, propane, coal, saw dust and diesel. Go to this page: http://eggtraymachines.net/egg-tray-drying-line/.
There are several types of egg trays depending on different region. The most frequent egg tray will be the 30- egg loading capacity. In addition to the 30 type egg tray, the assembly line can also produce 20, 25, 40, 45 and 54 type egg trays.
